ft-301系列智能粉  末電阻率測試系統 （升級版）

ft-301 series intelligent powder

resistivity test system (upgrade)

概述：采用一體化結構設計，將粉  末比電阻的測量與粉  體電阻率/電導率分析為一體式，測量與數據分析全部通過pc軟件完成，粉  體壓強與電阻值、電阻率、電導率值的變化關系；粉  體受到壓縮直至平穩時，描述了粉  體在壓縮體積變化過程中，電性能的變化趨勢，采用全自動操作模式運行，自動數據分析與管理。四端法測量模式。

overview: the integration structure design,

the powder ratio resistance measurements【敏感詞】powder resistivity/conductivity

analysis for one-piece, measurement【敏感詞】data analysis was done by the pc

software, the change relationship between the powder pressure【敏感詞】resistance,

the resistivity【敏感詞】the conductivity; powder is compressed until smooth,

describes the changing trend of the electrical properties in the process of

compression volume.  using automatic

operation mode, automatic data analysis【敏感詞】management. four terminal method of

measurement.

適用范圍：需要對電性能進行分析的導電性粉  末，如：碳素  粉  末廠、焦化廠、石化廠、粉  末冶金廠等生產加工企業部門；高等院校、科研部門，質量檢驗機構，質量管理部門，研發部門等。

scope of application: to analyze the

electrical conductive powder, such as: carbon powder plant, coking plant,

petrochemical plant, powder metallurgy factory etc production【敏感詞】processing

enterprises sector; university, scientific research department, quality

inspection organization, quality management department, r&d department,

etc.

 規格型號/ model

 ft-301a

 ft-301b

 ft-301c

 ft-301d

 1.電阻/ resistance

 1×10-8—2×105ω

 10-7～2×107ω

 10-6～2×106ω

 10-5～2×106ω

 2.電阻率范圍/ resistivity

 1×10-8—2×105ω-cm

 10-7～2×107ω-cm

 10-6～2×106ω-cm

 10-5～2×106ω-cm

 3.電導率/ conductivity

 5 ×10-5～1×108ms/cm

 5×10-7～107ms/cm

 5×10-6～106ms/cm

 5×10-6～105ms/cm

 4.測試電流范圍/ current

 0-10a，最小100ua

 1μa，10μa，100μa，1ma，10ma，1000ma

 5.測量電壓量程/ voltage

 0-2v；分辨率： 0.1μv

 精度0.1％

 電壓量程/ voltage：2mv  分辨率/ 20mv 200mv 2v resolution：0.1uv  測量精度±（0.1％）/、 accuracy ± (0.1％)

 6.電流精度/ current accuracy

 ±0.1％

 ±0.1％

 ±0.2％

 7.電阻精度/ resistance accuracy

 ≤0.3％標準電阻/ standard resistance

 分辨率0.01μω

 ≤0.3％標準電阻/ standard resistance

 分辨率0. 1μω

 8.pc軟件界面/display

 電阻值、電阻率、電導率值、溫度、壓強值、單位自動換算、橫截面、高度等

 resistance,

 resistivity, conductivity, temperature, pressure value, the unit

 automatically conversion, cross-section, height

 9.測試方式/test mode

 四端測量法/four-terminal measurement

 method

 10.傳感器壓力/pressure sensors

 200kg；(其他規格可以定制) / (other specifications can be customized)

 11.粉  末模具/powder mold

 模具：內徑10mm；高：25mm ；內徑20mm；高：25mm（選購）

 mold:

 inner diameter 10mm, height: 25mm,

 inner

 diameter 20mm, height: 25mm (choose to buy)

 12.工作電源/power supply

 輸入: ac 220v±10％ ,50hz  功 耗：<60w

 input:

 ac220v ± 10％, 50hz power consumption: <60w

 13. 主機外形尺寸/dimensions

 約h700mm*l650mm*d300mm

 about

 h700mm*l650mm*d300mm

 14.凈重量/net weight

 約45kg

 about

 45kg

 15. 標配外選購/others buy

 1.標準校準電阻1-5個；2.電腦和打印機依據客戶要求配置；4.計量證書1份

 1.

 standard calibration resistor 1-5.

 2.

 computers【敏感詞】printers based on customer configuration requirements.

 3.

 measurement certificate 1.
